liquid nitrogen tunnel blast freezer for meat iqf machine for fruits vegetables iqf ginger

Place of Origin : Guangdong, China

Brand Name : DJL

Packaging Details : sea shippment package

Supply Ability : 60 set per month

Price : negotiable

Certification : ISO9001,CE

MOQ : 1 SET

Delivery Time : 45 working days

Payment Terms : T/T

Model Number : DJL-QFL-1615

Type : Tunnel Freezer

Mode : ODM / OEM / Common design

Material : use stainless steel 304

Refrigerant : use Liquid nitrogen

Application : Fish&shrimp, seafood, poultry, fruit, high value-added food

Port : from Shenzhen

Contact Now

liquid nitrogen tunnel blast freezer for meat iqf machine for fruits vegetables iqf ginger

Compared with the cabinet type machine, the tunnel type is more conducive to mass production and factory work. It can cooperate with labor and effectively save human resources.Using liquid nitrogen for quick freezing not only has a very fast freezing speed, but also preserves the taste and nutrition of food to the utmost extent. In addition, nitrogen, as a gas in the air, is non-toxic, tasteless and very safe.

Model	Tunnel length (mm)	Wire belt width (mm)	Tunnel height (mm)	Power (KW)	freezing capacity (kg/h)
DJL-QFL-1206	6000	1200	1750	10	400-600
DJL-QFL-1209	9000	1200	1750	12	800-1000
DJL-QFL-1212	12000	1200	1750	18	1000-1200
DJL-QFL-1609	9000	1600	1750	15	1000-1200
DJL-QFL-1612	12000	1600	1750	28	1800-2100
DJL-QFL-1618	18000	1600	1750	32	2000-2500
DJL-QFL-1815	15000	1800	1750	28	2000-2500
DJL-QFL-1818	18000	1800	1750	32	2200-2800
DJL-QFL-1824	24000	1800	1750	46	2800-3500

Liquid nitrogen quick freezing system diagram

1.liquid nitrogen freezing tunnel

2.liquid nitrogen tank

3.tank base

4.exhaust duct

5.exhaust fan

6.liquid nitrogen pipeline

Equipment material:	SUS304 stainless steel
Working temperature:	-150℃~room temperature
Temperature control precision:	±2℃
Temperature uniformity:	±5℃
Cooling rate:	≥20℃/min
Heating rate:	≥5℃/min
Distribution specification:	380V/50HZ

FAQ:

1. What are your main products? In which areas?

Our products are of many types and specifications, such as the cabinet type, box type and tunnel type, etc. These series products have been widely used in many domestic and foreign areas, such as the food processing, mechanical engineering, genetic engineering, precision electronic, medical research, plant conservation, aerospace and rear livestock, etc.

2. What certificate do you have?

Passed the ISO9001 Management System Certification in 2019.

3. How to send the equipment to my country?

By sea, using 20'GP, 40'GP or 45'GP containers, depends on size of the equipment.

4. How much liquid nitrogen will be consumed for freezing foods?

Generally 1:1, that is 1 ton nitrogen for 1 ton food The comsumption rate is 1:1 to 1:1.5, actual consumption depends on the dimension and water content.
